Elevation Line Tool

Requirements:

• The Site layer is activated
• Draw an elevation line inside the outline of a custom terrain

To add an elevation line:

1. Click on the floor plan to locate the beginning of the elevation line.
2. Click several more times to place corners.
3. Double-click to locate the end of the elevation line.

To edit the shape of the line, double-click on it. In the editing mode, you will be able to move, add or delete points of the elevation line.

---
